AQUA VICTORIA – LED

Lighting engineered to meet every one of land-based aquacultures unique convergence of environmental, biological, and operational demands.



The AQUA VICTORIA, an IP66-rated land based aquaculture luminaire engineered to optimise fish growth, feed efficiency, and welfare in RAS and tank environments.

In land-based aquaculture, lighting precision is a production variable — not an afterthought. The AQUA VICTORIA delivers a fish-optimised aqua spectrum at 146 lm/W efficacy across 120W and 220W configurations, engineered specifically to accelerate growth, improve feed conversion efficiency, and reduce stress in RAS, tank, and flow-through systems. IP66-rated marine-based aluminium construction, DALI dimming from 1–100%, 100% flicker-free operation, IK10 impact resistance, 70,000-hour LED lifetime, and a five-year warranty combine into the standard for land-based aquaculture lighting.

Product Advantages

  • Fish growth rate increases as the optimised aqua spectrum drives biological development efficiently.
  • Feed efficiency improves as stress-free light conditions support consistent, natural feeding behaviour.
  • Fish welfare is enhanced with 100% flicker-free operation eliminates chronic light-induced stress responses.
  • Light pollution is minimised with precise 115° beam distribution contains light where production requires.
  • Operational cost is reduced, 146 lm/W efficacy and 70,000h lifetime minimise energy and replacement cost.
  • Corrosion resistance is assured using marine-based aluminium coating which withstands aggressive aquaculture environments.
  • Investment is protected with five-year warranty and IK10 impact rating deliver operational confidence throughout.

Additional information

Features & Benefits

Fish-Optimised Spectrum Precision aqua/fish spectrum targets the biological wavelengths that drive growth acceleration, feed efficiency improvement, and stress reduction, delivering the spectral precision that broad-spectrum alternatives cannot achieve in controlled aquaculture environments.
High-Efficacy 146 lm/W LED Output 120W (17,500 lm) and 220W (32,000 lm) configurations deliver exceptional luminous efficacy, maximising biological light intensity at tank level while minimising the energy consumption that determines long-term operational lighting cost.
IP66 Marine Environment Rating IP66 dust-tight and high-pressure water jet protection, providing the ingress resistance required for continuous operation in the high-humidity, water-spray, and wash-down conditions of working land-based aquaculture facilities.
Marine-Based Aluminium LM6 Construction LM6-quality aluminium with marine-based coating delivers the corrosion resistance, structural integrity, and long-term dimensional stability that aggressive aquaculture environments - including salt spray, humidity, and chemical exposure - demand.
DALI Dimming, 1 to 100% Flicker-Free Full DALI dimming from 1-100% with 100% flicker-free operation, enables precise photoperiod programming and intensity management without the stress response that flickering or abrupt light transitions trigger in fish.
115° Wide Beam Angle Distribution 115-degree beam angle across two planes delivers even light distribution across the full tank surface, ensuring consistent biological stimulation across every fish in the system without hotspots or undertreated dark zones.
70,000-Hour LED Lifetime and Five-Year Warranty Industry-leading 70,000-hour LED lifetime minimises replacement frequency and maintenance intervention, supported by a five-year manufacturer's warranty that protects the production-critical lighting investment across years of continuous operation.

Full Description

Land-based aquaculture — Recirculating Aquaculture Systems, flow-through systems, and controlled tank environments represent the most technically advanced and most precisely manageable form of fish production available. In these environments, every production input can be monitored, adjusted, and optimised: water temperature, oxygen levels, feed composition, stocking density, and water quality are all subject to continuous management. Lighting is one of the most powerful of those inputs and in land-based systems, it is also one of the most frequently underspecified. The AQUA VICTORIA is designed to close that gap, bringing the same precision to lighting management that high-performing land-based operations apply to every other production variable.

Light as a Production Input
The relationship between light and fish biology is direct, measurable, and commercially significant. Light spectrum influences which biological responses fish photoreceptors trigger with specific wavelengths driving feeding activity, growth hormone regulation, circadian rhythm entrainment, and the photoperiod-dependent developmental processes that determine maturation timing and growth rate. The AQUA VICTORIA LED spectrum is not a generic LED colour temperature approximation, it is a specifically engineered spectral composition targeted at the wavelength ranges that matter most for the fish species and developmental stages common in land-based aquaculture operations.

In hatchery and early-stage development applications, appropriate spectrum and intensity support the critical developmental processes of juvenile fish, promoting the growth rate and survival outcomes that determine the productivity of the hatchery phase. In grow-out RAS applications, consistent, high-quality light management supports the feed conversion efficiency and growth trajectory that determine the economics of the production cycle. The AQUA VICTORIA delivers a consistent, precisely characterised spectral output that performs the same way in every installation, providing the repeatability that production optimisation requires.

Flicker-Free Operation: The Welfare Imperative
Fish visual systems detect light flicker at frequencies far above the threshold of human perception. Flickering light at those frequencies constitutes a chronic environmental stressor, one that activates physiological stress responses, elevates cortisol levels, suppresses immune function, and diverts metabolic energy from growth to stress management. The cumulative impact of chronic light-induced stress on feed conversion efficiency, growth rate, and disease susceptibility in a production system is measurable and commercially significant. The AQUA VICTORIA’s 100% flicker-free operation removes that stressor entirely, ensuring that the biological benefit of the lighting programme is not undermined by the delivery mechanism, and that every fish in the system experiences the same consistent, stress-free light environment throughout the photoperiod.

DALI Dimming: Precision Photoperiod Management
The DALI dimming system provides full 1–100% intensity control through the industry-standard communication protocol for intelligent lighting management systems. In land-based aquaculture, photoperiod management – the deliberate programming of light and dark cycles – is a primary tool for influencing fish biology. Gradual dawn and dusk transitions reduce the stress response associated with abrupt light changes. Precise intensity programming allows light levels to be matched to the developmental requirements of fish at different life stages. And the ability to adjust photoperiod parameters remotely and precisely provides the management flexibility that optimising a production system across different species, seasons, and production phases requires.

115° Beam Distribution: Full Tank Coverage
The 115-degree beam angle across two planes is an engineering decision with direct production consequences. Uneven light distribution across a tank creates zones of differential biological stimulation, fish in well-lit zones receive different photoperiod signals than fish in dimly lit zones, creating the growth variation and behavioural segregation that undermines the uniform production outcomes that efficient aquaculture management targets. The AQUA VICTORIA’s wide, even beam distribution ensures that every fish in the tank receives consistent light intensity and spectral quality, regardless of their position — supporting the uniform growth and feeding behaviour that converts efficiently into harvest outcome.

Construction and Environmental Durability
The working environment of a land-based aquaculture facility presents a combination of challenges that general industrial lighting equipment is not rated to withstand. High ambient humidity, water spray from aeration and water management systems, aggressive cleaning chemicals applied during facility sanitation, and the physical handling associated with maintenance access in confined tank spaces all challenge lighting equipment integrity over operational service life. The AQUA VICTORIA’s LM6-quality aluminium construction with marine-based coating provides the structural integrity and corrosion resistance that these conditions demand. IP66 rating provides documented protection against both dust ingress and the high-pressure water jets that facility cleaning requires. IK10 fixture impact rating and IK8 glass impact rating provide the mechanical robustness that handling and operational contact in confined aquaculture environments produce.

Operational Economics and Investment Protection
The 146 lm/W luminous efficacy of the AQUA VICTORIA places it among the most energy efficient aquaculture luminaires available, delivering more biologically effective light per watt consumed than conventional aquaculture lighting alternatives, and reducing the energy cost of maintaining the lighting conditions that production performance requires. For land-based facilities running continuous or extended photoperiod programmes, the difference in energy cost between high-efficacy and standard-efficacy lighting compounds significantly across the operating hours of the installation’s service life.

The 70,000-hour expected LED lifetime reduces maintenance intervention frequency to a minimum, and the five-year manufacturer’s warranty provides the investment confidence that a production-critical infrastructure decision of this significance requires. For operations where fish health, growth performance, feed efficiency, and operational cost are managed as a unified production system, the HATO Aqua Victoria is the lighting specification those priorities converge on.

Technical Details

Models Aqua Victoria, 120W, Aqua Victoria 220W
Power Consumption 120 W, 220 W
Light Output 17,500 lm, 32,000 lm
Efficacy 146 lm/W
Beam Angle 115°, 2 Planes
Operating Voltage 220 – 240 VAC
Light Source LED
Dimmer Type DALI
Flicker-Free Yes - 100%
Dim Range 1–100%
LED Lifetime 70,000 hours
Operating Temperature -20°C to +50°C
Storage Temperature -20°C to +50°C
Net Weight 7.5 kg
Base Material Aluminium LM6 — Marine-Based Coating
IK Rating Fixture 10, Glass 8
IP Rating IP66
Country of Origin The Netherlands

Technical Details Download

Certifications

CE Certification HATO AQUA VICTORIA holds CE certification and IP66 rating, independently verified to European standards for aquaculture luminaire performance, safety, and marine-environment durability.

Warranty

Manufacturer's Warranty The total warranty period of this product consists of 3 years full warranty + 5 years decreasing warranty. This 8-year warranty is issued on the basis of the prescribed specifications.

The first 3 years of the warranty are covered by our General Warranty Conditions. These can be found at the top of this page.

From the 4th year, a decreasing warranty applies. The decreasing warranty comes into effect from the moment the full warranty ends. From this moment on, a discount applies to the purchase of a replacement product.

The discount is calculated as follows:
(total warranty period - period already used) / total warranty period * current price of replacement product.

This warranty takes effect from the date of production unless it is conclusively established what the delivery date is.

Unless stated otherwise, Lumen maintenance is specified based on L70B50. This means that at the end of the specified duration, 50% of the lamps still have at least 70% of the specified Lumen output. Warranty based on Lumen maintenance can therefore only be claimed on the basis of measurement data of all lamps in a project.
Product: HATO | AQUA VICTORIA – LED
